Product
FAMV-6A26SLAB/CM(BK)
CAT6A Ethernet high flexible cable
Application
Appropriate for cable chain wiring for high-speed moving.
CAT6A
High flexible cable with UL,cUL at 300V 75℃. (Category : DUZX,DUZX7,AVLV2,AVLV8)
EtherCAT
Feature
It passes Vertical-trai Flame Test of UL,ｃUL.
Flame resisting : UL VW-1, cUL FT1.
Oil, heat,fleme resisting flexible PVC material is used for sheath.
CM listing standard is acquired and it corresponds to NFPA70.
Double shielded.
Application
Appropriate for cable chain wiring for high-speed moving.
CAT6A
High flexible cable with UL,cUL at 300V 75℃. (Category : DUZX,DUZX7,AVLV2,AVLV8)
EtherCAT
Feature
It passes Vertical-trai Flame Test of UL,ｃUL.
Flame resisting : UL VW-1, cUL FT1.
Oil, heat,fleme resisting flexible PVC material is used for sheath.
CM listing standard is acquired and it corresponds to NFPA70.
Double shielded.
| Category | Signal and instrumentation, Ethernet |
|---|---|
| AWG | 26 - 26 |
| SQ（mm2） | 0.15 - 0.15 |
| Core (pair) | Multi |
| Use | Moving |
| Shield | Have |
| Voltage | 30V |
| Rating temperature | 80°C |
| Standards |
    |
| Characteristics | Oil, Heat, Flexible, Twisting |
