Product
TC LF TC-ER LF
Application
It is possible to use it also for WET LOCATION.
Electric equipment cable with UL at 600V, 90°C. (Category : QPOR)
Obtaining UL Listed TC, this cable compliants to NFPA70,79.
Suits the TC-ER attestation. ※2core product is excluded. (not"-ER")
Feature
Heat resistant PVC material is used to insulation.
Oil, heat resistant and Flexible PVC sheath material is used.
It passes Vertical-Tray Flame Test of UL.
It is possible to use it also for WET LOCATION.
Electric equipment cable with UL at 600V, 90°C. (Category : QPOR)
Obtaining UL Listed TC, this cable compliants to NFPA70,79.
Suits the TC-ER attestation. ※2core product is excluded. (not"-ER")
Feature
Heat resistant PVC material is used to insulation.
Oil, heat resistant and Flexible PVC sheath material is used.
It passes Vertical-Tray Flame Test of UL.
| Category | Power |
|---|---|
| AWG | 18 - 2 |
| SQ（mm2） | 0.75 - 30 |
| Core (pair) | Multi |
| Use | Fix |
| Shield | None |
| Voltage | 600V |
| Rating temperature | 90°C |
| Standards |
 |
| Characteristics | Oil, Heat |
