Product
SUNLIGHT 3SX LF
PVC insulated oil flexible cord for electronics wiring(with shield)
Application
AC 300V or less of the environmental type cable as machine tools,construction machinery, applications under harsh conditions, such as a robot power circuit.
Oil, flexibility, use of shielded.Rated voltage：300V. Temp：60℃.
Feature
Oil, heat, flame retardant and soft PVC forsheath.
Sheath material is non-migratory against ABS and PS resin.
Chemical, water, abrasion, cold resistance PVC for sheath.
Flame resisting : UL VW-1.
0.75mm2 ~5.5mm2 cables conform toElectrical Appliance and Material Safety Law.
(0.5mm2 cables used in less than 100V outof Electrical Appliance and Material Safety Law)
Application
AC 300V or less of the environmental type cable as machine tools,construction machinery, applications under harsh conditions, such as a robot power circuit.
Oil, flexibility, use of shielded.Rated voltage：300V. Temp：60℃.
Feature
Oil, heat, flame retardant and soft PVC forsheath.
Sheath material is non-migratory against ABS and PS resin.
Chemical, water, abrasion, cold resistance PVC for sheath.
Flame resisting : UL VW-1.
0.75mm2 ~5.5mm2 cables conform toElectrical Appliance and Material Safety Law.
(0.5mm2 cables used in less than 100V outof Electrical Appliance and Material Safety Law)
| Category | Signal and instrumentation, Power |
|---|---|
| AWG | - |
| SQ（mm2） | 0.5 - 1.25 |
| Core (pair) | Multi |
| Use | Fix |
| Shield | Have |
| Voltage | 300V |
| Rating temperature | 60°C |
| Standards |
 |
| Characteristics | Oil |
