HIV LF

600V Grade heat-resistant polyvinyl chloride insulated wires

Application
Wiring of electrical installation and apparatus not exceeding 600V.
Applications of high temperature location.
Rated voltage:600V. Temp:75°C.

Feature
Use a heat-resistant PVC to insulation compared to IV 1.2 times the allowable current.
Heat resistance75°C.
Reference to JIS C 3317.
1.25mm2~100mm2 wires conform to Electrical Appliance and Material Safety Law.

Category Signal and instrumentation, Power
AWG -
SQ(mm2 1.25 - 200
Core (pair) Single
Use Fix
Shield None
Voltage 600V
Rating temperature 75°C
Standards PSE
Characteristics Oil, Heat
