Product
FAFX-5E25SLAB/CM(YL)(BU)
CAT5e Ethernet exible cable (YL)or(BU)
Application
Appropriate for wiring in excellent flexibility.
CAT5e
Flexible cable with UL, cUL at 300V,75°C. (Category : DUZX, DUZX7, AVLV2, AVLV8.)
CC-Link IE, EtherCAT
Feature
It passes Vertical-trai Flame Test of UL, cUL.
Flame resisting : UL VW-1, cUL FT1.
Oil, heat,fleme resisting flexible PVC material is used for sheath.
CM listing standard is acquired and it corresponds to NFPA70.
Double shielded.
Application
Appropriate for wiring in excellent flexibility.
CAT5e
Flexible cable with UL, cUL at 300V,75°C. (Category : DUZX, DUZX7, AVLV2, AVLV8.)
CC-Link IE, EtherCAT
Feature
It passes Vertical-trai Flame Test of UL, cUL.
Flame resisting : UL VW-1, cUL FT1.
Oil, heat,fleme resisting flexible PVC material is used for sheath.
CM listing standard is acquired and it corresponds to NFPA70.
Double shielded.
| Category | Signal and instrumentation, Ethernet |
|---|---|
| AWG | 25 - 25 |
| SQ（mm2） | 0.2 - 0.2 |
| Core (pair) | Multi |
| Use | Fix |
| Shield | Have |
| Voltage | 30V |
| Rating temperature | 80°C |
| Standards |
    |
| Characteristics | Oil, Heat |
